Brand: SharpStar

SharpStar 140PH Premium APO S Triplet Refractor (140PH)

140PH

Brand: SharpStar

SharpStar 140PH Premium APO S Triplet Refractor (140PH)

140PH

We love refractors and this one is huge! 140mm of premium glass will bring out mind blowing detail in the faintest deep sky objects. This will take your astrophotography to the next level.

Discontinued see the: 140APO

  • 140mm aperture
  • 910mm focal length
  • f6.5
  • f4.8 with optional reducer
  • Beautiful wide views and incredible detail
$5,398.65 CAD

Easy Payment Options with .

What is a Backorder?
$5,398.65 CAD

Easy Payment Options with .

What is a Backorder?
Free Expert Support
Stress Free, Secure Shopping
30 Day Return Policy
Price Match Promise

Recommended Accessories

Why We Love It Full Details What Can I See? What's in the Box? Specifications Reviews and Questions Articles, Videos, Software, Links

Why we love the SharpStar 140PH Premium APO S Triplet Refractor (140PH)

We love refractors and this one is huge! 140mm of premium glass will bring out mind blowing detail in the faintest deep sky objects. This will take your astrophotography to the next level.

Product Description

Sharpstar 140PH, a large-aperture APO astrograph, the very first in Sharpstar APO-series, finally comes to the market. It features pioneering double ED glass and triplet air-spaced lens structure. The focal ratio is properly designed of f/6.5 and its focal length is 910mm.

Most stock triplet APO lenses are regularly equipped solely with an ED glass aiming to reduce the achromatic aberration, whereas two of the 140PH lens set are ED glass, considerably enhancing the aberration control performance, offering a solid foundation for advanced visual observation and astrophotograph.

Sharpstar 140PH is equipped with a retractable dew shield and is wrapped with quality aluminum ally cover. The dedicated 4" large-size focuser allows both coarse and fine adjustment. Sharpstar 140PH also comes with a pair of streamline tube rings, a wide dovetail plate and a ergonomically-crafted handle. All the apparatus and accessories are packed and safely protected in an elegant aluminum chest.

The Sharpstar 140PH can be applied in many full-frame sky-imaging situations with the help of a full-frame flattener and reducer. The 3" 0.73× reducer can effectively lower the original focal ratio to f/4.8, catering to many special astrophographic needs, such as shorter exposure time, larger field of view and advance image quality.

What can I see with a SharpStar 140PH Premium APO S Triplet Refractor (140PH)?

Here are some simulated views of common objects. Results with your telescope will vary with viewing conditions, obrits, equipment and more.

Jupiter with

25mm Eyepiece - 36x Magnification

(Sold Separately)

Jupiter with

10mm Eyepiece - 91x Magnification

Sold Separately

Jupiter with

5mm Eyepiece - 182x Magnification

Sold Separately

Moon with 25mm Eyepiece

36x Magnification

(Sold Separately)

Moon with 10mm Eyepiece

91x Magnification

Sold Separately

Moon with 5mm Eyepiece

182x Magnification

Sold Separately

Andromeda with 36mm Eyepiece

25x Magnification

Sold Separately

Andromeda with 25mm Eyepiece

36x Magnification

(Sold Separately)

Andromeda with 10mm Eyepiece

91x Magnification

Sold Separately

What's in the Box

  • OTA
  • Pair of tube rings
  • Wide dovetail plate
  • Handle

Specifications

Aperture Size 140mm
Focal Length 910mm
Limiting Visual Magnitude 12.5
Focal Ratio f/6.5
Resolution 0.83 arc Seconds
Objective Lens Triplet Air-spaced APO (including two ED glass)
Tube Length 738.6mm (with the dew shield contracted)
Tube outer diameter 148mm
Net Weight 10.1kg
Gross Weight 11.7kg

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
M
M.K.K.
Sharp star 140ph

The scope arrived securely packaged in a fitted aluminum case. The fit and finish was of high quality. The 4 inch focuser was smooth and the reducer/flattener secured easily. Visually stars look sharp with no apparent false colour on bright objects. I haven’t had the opportunity to image through it yet but trust it will perform well. Happy so far
